NEO 3 Pro GNSS Module Feature:
1– Ublox M9N satellite receiver, accuracy up to 0.7m
2– Support BDS, GALILEO, GLONASS, GPS four satellite systems
3– Support simultaneous reception of four satellite systems
4– Triple filters design
Introduction:
NEO 3 Pro is a M9N navigation product using the DroneCAN communication protocol. Integrated positioning system, magnetic compass, control status light, control siren, barometer in one, industrial grade magnetic compass, can receive four major satellite systems navigation and positioning signals at the same time.
Product Parameters | |
| Processor | STM32F412(32 Bit Arm® Cortex®-M4,100MHz, 512KB FLASH, 256KB RAM) |
| Compass | RM3100 |
| Barometer | MS5611 |
| GNSS Receiver | UBLOX NEO M9N |
| Buzzer | Passive buzzer |
| Safety Switch | Physical button |
| Number of Concurrent GNSS | 4(BDS、GALILEO、 GLONASS、 GPS) |
| GNSS Augmentation System | SBAS：WAAS,EGNOS,MSAS QZSS：L1s(SAIF) other：RTCM3.3 |
| Frequency Band | GPS：L1C/A GLONASS：L10F BDS：B1I GALILEO：E1B/C |
| Horizontal Accuracy | 2.0m(Highest measured value is 0.7m) |
| Speed Accuracy | 0.05m/s |
| Nav. update rate | 25Hz(Max) |
| Protocol | DroneCAN |
| Port Type | GHR-04V-S |
| Acquisition | Cold start：24s Hot start：2s Aided start：2s |
| Number of Satellites(MAX) | 32+ |
| Sensitivity | Tracking and nav-167dBm Cold start Hot start-148dBm Reacquisition -160dBm |
| Supported Controller | CUAV series,Pixhawk series |
| Wave Filtering | SAW+LNA+SAW |
| Anti Electromagnetic/ Radio Frequency Interference | EMI+RFI |
| Upgrade firmware | Support |
| Support Control Type | ArduPilot/PX4 |
| Input Voltage | 4.7-5.2V |
| Operating Temperature | -10 ~ 70℃ |
| Size | 60 × 60 × 16mm |
| Weight | 33g |
